 Post subject: Sulaco Locker Widget: a work in progress
PostPosted: Tue Aug 14, 2012 10:33 pm
Prop Churner Outer
User avatar

Location: Bath, Maine
Service Number: A03/TQ1.0.12143G1
Country: United States
Attachment:
mockup.jpg [ 203.17 KiB | Viewed 6184 times ]


This is just a rough first fitting of the pieces. I have a 3" floppy port (not identical to the SC one but close enough), a calculator that will be built up to have round buttons like the SU one, and 80% of the upper parts framed up in foam core. I still need to add the two lights and the wire mesh inside the righthand indentation (visible in other shots of the Widget).

I'm at a loss as to what the middle part is that I haven't framed out yet. I can make something that has a similar look, but I don't know if it is supposed to be a latch or what. Any thoughts?

I'm going to re-watch the scene to see how the lockers are openned. Maybe this will provide a clue.

So more trimming and then some paint are next for this.

Comments welcome!
